Technical Specifications
Operation Mode:Instant-on type
Overall Dimensions:55.5 × 41 × 84 mm
Time Delay Range:4 ranges
-
A: 0.05-0.5s / 5s / 30s / 3min
-
B: 0.1s-1s / 10s / 60s / 6min
-
C: 0.5-5s / 50s / 5min / 30min
-
D: 1-10s / 100s / 10min / 60min
-
E: 5-60s / 10min / 60min / 6h
-
F: 0.25-2min / 20min / 2h / 12h
-
G: 0.5-4min / 40min / 4h / 24h
Rated Voltage:
-
AC: 24V, 36V, 48V, 110V, 220V, 380V (50/60Hz)
-
DC: 12V, 24V, 48V, 110V, 220V
Contact Capacity:5A @ 250VAC, resistive load
Repeat Error:< 0.5% ± 20ms
Voltage Error:< 1% ± 20ms
Power Consumption:
-
AC220V: 2.9VA; AC110V: 1.9VA
-
DC24V: 1.3W / 2.4W (depending on model)
Temperature Error:< 2% ± 20ms
Reset Time:100ms (max.)
Ambient Temperature:-10℃ ~ +55℃
Mechanical Life:1 × 10⁷ operations
Electrical Life:1 × 10⁵ operations
Net Weight:Approx. 140g
Certifications:CCC, CE
Features:
-
Adopts large-scale dedicated IC, with wide time delay range and high reliability.
-
ST3P (A, C, G) models feature 4-step time delay control.
-
ST3PS is a single-range model, offering low cost and easy operation.
-
With optional accessories, the relay can be mounted via screw, DIN rail, or panel mounting.
-
External type ST3PSZ (JSZ0-SZ) is also available.
