| Item | Specification | Item | Specification |
|---|---|---|---|
| Model | TX-LD-01(L) | Vertical Beam Angle | Vertical ≥20° |
| Power Supply | DC12~24V | Horizontal Beam Angle | 360° |
| Power Frequency | DC (Direct Current) | Overall Dimensions | 141mm×141mm×120mm (L×W×H) |
| Average Power Consumption | ≤3W | Mounting Dimensions | 130mm×130mm×M4 |
| Operating Mode | 60~90 Flashes/Min | Ambient Temperature | -40℃ ~ +55℃ |
| Emission Color | Yellow | Weight | 1kg |
| Light Source | LED | Wind Resistance | 240km/h |
| Housing Material | Aviation-Grade Aluminum Alloy | Lens Material | Optical-Grade Polycarbonate (PC) |
| Mounting Structure | Optional Flange Mounting Kit | Energy Efficiency | ≥98% |
| Light Source Lifespan | ≥200,000 Hours | Protection Class | IP66 |
| Surge Protection Rating | 3kA | Relative Humidity | 0% ~ 95% |
| Rain Resistance | Suitable for exposure to rain from any wind direction | Salt Spray Resistance | Suitable for exposure to salt spray environment |
| Radiation Resistance | Suitable for exposure to solar radiation | Insulation Performance | Between input terminal and housing: 1.414kVdc, 10S no breakdown |
| Vibration Resistance | 10~500Hz, 2G, 10min/cycle, 60min for each X/Y/Z axis | EMC Compliance Standard |
Emission: EN55022 (CISPR22) Class A
|
| Mean Time Between Failures (MTBF) | ≥200,000 Hours, MIL-HDBK-217F (25℃) | Leakage Current | ＜10μA |
| Electric Shock Protection | N/A | Altitude Rating | ≥5500m |
| Effective Luminous Intensity | Night: 200cd~400cd | - | - |
| Light Control Threshold | 50/500Lux | - | - |
