| Item | Specification | Item | Specification |
|---|---|---|---|
| Model | TX-MB-01(L) | Vertical Beam Angle | 3° |
| Power Supply | AC220V, DC180V | Horizontal Beam Angle | 360° |
| Power Frequency | 50Hz ~ 60Hz | Overall Dimensions | 215mm×215mm×204mm |
| Average Power Consumption | ≤2.5W | Mounting Dimensions | φ185~200mm×4×M8 |
| Operating Mode | 20 Flashes/Min | Ambient Temperature | -40℃ ~ +55℃ |
| Emission Color | Red | Weight | 2.3kg (bracket not included) |
| Light Source | LED | Wind Resistance | 240km/h |
| Housing Material | Aviation-Grade Aluminum Alloy | Lens Material | Optical-Grade Polycarbonate (PC) |
| Light Source Lifespan | ≥200,000 Hours | Protection Class | IP65 |
| Surge Protection Rating | 5kA | Relative Humidity | 0% ~ 95% |
| Rain Resistance | Suitable for exposure to rain from any wind direction | Vibration Resistance | 10~500Hz, 2G, 10min/cycle, 60min for each X/Y/Z axis |
| Salt Spray Resistance | Suitable for exposure to salt spray environment | Insulation Performance | Between input terminal and housing: 1.414kVdc, 10S no breakdown |
| Radiation Resistance | Suitable for exposure to solar radiation | Light Control Threshold | 50/100Lx |
| Leakage Current | ＜10μA | Mean Time Between Failures (MTBF) | ≥200,000 Hours, MIL-HDBK-217F (25℃) |
| Electric Shock Protection | Yes | Anti-Drop Device | Yes |
| Effective Luminous Intensity | Night: 2000cd | - | - |
| EMC Compliance Standard |
Emission: EN55022 (CISPR22) Class A
|
- | - |
Welcome to consult China Medium-Intensity Aviation Obstruction Light suppliers. We have more than 10 years of foreign trade supply experience and have provided high-quality shipping equipment to dozens of countries around the world. We provide you with high-quality services and preferential prices customized by manufacturers. You can get a free quote online or leave a message below and we will reply to you within 24 hours.
