250~500t inland transport ship, 9~12m yacht, passenger ship, etc.
| Items | YC4A Series marine diesel engine | ||||||||
| Model | YC4A220L-C20 | YC4A200L-C20 | YC4A165L-C20 | YC4A120L-C20 | YC4A140Z-C20 | YC4A120Z-C20 | YC4A100Z-C20 | YC4A70Z-C20 | YC4A55Z-C20 |
| Number of cylinders - bore × stroke (mm) | 4-108×132 | 4-108×132 | 4-108×132 | ||||||
| Displacement (L) | 4.837 | 4.837 | 4.837 | ||||||
| Number of valves per cylinder | 2 | 2 | 2 | ||||||
| Induction system | Turbocharged & intercooled | Turbocharged & intercooled | Turbocharged & intercooled | ||||||
| Rated power/speed (kW(Ps)/r/min) | 162(-220)/2300 | 147(200)/2300 | 120(165)/1800 | 90(120)/1500 | 103(140)/2300 | 90(120)/2000 | 75(100)/1800 | 53(70) /1500 | 40(55) /1500 |
| Overload power/speed (kW(Ps)/r/min) | 178.2(-240)/2374 | 161.7(-220)/2374 | 132(-180)/1858 | 99(-135)/1548 | 113.3 (-155)/2374 | 99(135)/2064 | 82.5(110)/1858 | 58.3(80) /1548 | 44(-60)/1548 |
| Min. specific fuel consumption(g/kW·h) | ≤200 | ≤200 | ≤200 | ||||||
| Certificates | ZC、CCS、EIAPP、China II | ZC、CCS、China II | ZC、CCS、China II | ZC、CCS、China II | |||||
| Diemension (L×W×H) (mm) | 570 | 570 | 570 | ||||||
| Dry weight (kg) | 1143×853×1120 | 1143×853×1120 | 1076×853×1120 | 1076×853×1120 | |||||
Mainly supporting 600~1,200t inland transport ships, 20~30m cruise ships, 15~25m fishing boats, etc.
| Items | YCA08 Series marine diesel engine | ||
| Model | YCA08320L-C20 | YCA08300L-C20 | YCA08280L-C20 |
| Number of cylinders - bore × stroke (mm) | 6-108×132 | ||
| Displacement (L) | 7.25 | ||
| Number of valves per cylinder | 2 | ||
| Induction system | Turbocharged & intercooled | ||
| Rated power/speed (kW(Ps)/r/min) | 235(320)/2300 | 219(300)/2000 | 206(280)/1800 |
| Overload power/speed (kW(Ps)/r/min) | 258.5(350)/2374 | 241(330)/2064 | 226.6(310)/1858 |
| Min. specific fuel consumption of external characteristics (g/kW·h) | ≤200 | ||
| Certificates | ZC、CCS、EIAPP、China II | ||
| Diemension (L×W×H) (mm) | 1300×903×1067 | ||
| Dry weight (kg) | 860 | ||
800~1,600t inland transport ship, 18~28m fishing boat, cruise ship, etc.
| Model | YC6MJ365L-C23 | YC6MJ410L-C23 | YC6MJ450L-C23 |
| Number of cylinders - bore × stroke (mm) | 6×131×145 | ||
| Displacement (L) | 11.73 | ||
| Number of valves per cylinder | 4 | ||
| Induction system | Turbocharged & intercooled | ||
| Rated power/speed (kW(Ps)/r/min) | 267（365）/1500 | 300（410）/1800 | 330（450）/2100 |
| Overload power/speed (kW(Ps)/r/min) | 293.7（400）/1548 | 330（450）/1858 | 363（495）/2168 |
| Min. specific fuel consumption of external characteristics (g/kW·h) | ≤188 | ||
| Certificates | ZC、CCS、EIAPP、China II | ||
| Diemension (L×W×H) (mm) | 1834×1028×1278 | ||
| Dry weight (kg) | 1200 | ||
Mainly supporting 5,000~8,000t inland transport ships, engineering ships, passenger ships, 30~50m fishing boats, etc.
| Items | YC6CL Series marine diesel engine | ||
| Model | YC6CL960L-C23 | YC6CL1035L-C23 | YC6CL1135L-C20 |
| Number of cylinders - bore × stroke (mm) | 6-200×290 | ||
| Displacement (L) | 54.6 | ||
| Number of valves per cylinder | 4 | ||
| Induction system | Turbocharged & intercooled | ||
| Rated power/speed (kW(Ps)/r/min) | 706（960）/1000 | 760（1035）/1000 | 835（1135）/1000 |
| Overload power/speed (kW(Ps)/r/min) | 776.6（1060）/1032 | 836（1140）/1032 | 918.5（1250）/1032 |
| Min. specific fuel consumption of external characteristics (g/kW·h) | ≤195 | ||
| Certificates | ZC、CCS、EIAPP、China II | ||
| Diemension (L×W×H) (mm) | 2496×1150×2172 | ||
| Dry weight (kg) | 5380 | ||
