Mainly support public service ships, yachts of 6~11m and 24~40kW boat gensets
|
Model |
YC4FA150L-C20 | YC4FA130L-C20 | YC4FA115L-C20 | YC4FA100L-C20 | YC4FA100L-C23 |
|
Number of cylinders - bore × stroke (mm) |
4-96×103 | ||||
|
Displacement (L) |
2.98 | ||||
|
Number of valves per cylinder |
2 | ||||
|
Induction system |
Turbocharged & intercooled |
||||
|
Rated power/speed (kW(Ps)/r/min) |
110（150）/3100 | 95（130）/3100 | 85（115）/3100 | 73（100）/2100 | 73（100）/2950 |
|
Overload power/speed (kW(Ps)/r/min) |
121(165) /3200 |
104.5(142) /3200 |
93.5(127) /3200 |
80.3(110) /2168 |
80.3(110) /3045 |
|
Min. specific fuel consumption of external characteristics (g/kW·h) |
≤201 | ||||
|
Certificates |
CCS, EIAPP, China II |
||||
|
Dimension (L×W×H) (mm) |
828×663×724 | ||||
|
Dry weight (kg) |
380 | ||||
Mainly support public service ships of 12~15m and tourist ships and yachts of 18~25m
| Model | YC6A125L-C20 | YC6A190L-C20 | YC6A200L-C22 | YC6A260L-C23 | YC6A280L-C22 |
| Cylinder quantity - bore/stroke(mm) | 6-108×132 | ||||
| DisplacementL | 7.252 | ||||
| Number of valves per cylinder | 2 | ||||
| Induction system | Turbocharged & intercooled | ||||
| Rated power/speed(kW（Ps）/r/min) | 90（125）/1500 | 140（190）/1800 | 145（200）/1500 | 191（260）/2300 | 206（280）/2500 |
|
Overload power/speed (kW(Ps)/r/min) |
99（135）/1548 | 154（210）/1858 | 159.5（220/1548 | 210（285）/2374 | 227（310）2580 |
| Min. specific fuel consumption of external characteristicsg/kW.h | ≤198 | ||||
| Certificates | ZC、CCS、China II | ZC、CCS、EIAPP、China II | |||
| Diemension（Length × width × height）（mm） | 1433×899×976 | ||||
| Dry weight（kg） | 780 | ||||
Application: high-speed ships and law enforcement boats below 20m, public service ships, yachts and tourist ships of 20~40m, etc.
| Model | YC6MJ800L-C20 | YC6MJ750L-C20 | YC6MJ700L-C20 | YC6MJ650L-C20 | YC6MJ600L-C20 | |
| Cylinder quantity - bore/stroke(mm) | 6-131×145 | |||||
| DisplacementL | 11.726 | |||||
| Number of valves per cylinder | 4 | |||||
| Induction system | Turbocharged & intercooled | |||||
| Rated power/speed(kW（Ps）/r/min) | 588（800）/2400 | 552（750）/2400 | 515（700）/2300 | 478（650）/2300 | 441（600）/2100 | |
| Overload power/speed(kW（Ps）/r/min) | / | / | / | 525.8（715）/2374 | 485.1（660）/2167 | |
| Min. specific fuel consumption of external characteristicsg/kW.h | ≤205 | ≤205 | ≤205 | ≤200 | ||
| Certificates | CCS、EIAPP、China II | CCS、EIAPP、China II | ||||
| Diemension（Length × width × height）（mm） | 1570×1000×1000 | |||||
| Dry weight（kg） | 1250 | |||||
Welcome to consult China High-speed boat engine suppliers. We have more than 10 years of foreign trade supply experience and have provided high-quality shipping equipment to dozens of countries around the world. We provide you with high-quality services and preferential prices customized by manufacturers. You can get a free quote online or leave a message below and we will reply to you within 24 hours.
