MINE USE FLAME-RESISTANT FABRIC CONVEYOR BELT

Product Performance:Flame retardant type with self-extinguishing, can prevent fire accidents and the spread of fire.

Production process: The tape is arranged horizontally with spring steel strips as the skeleton, separated by film in the middle and covered with rubber canvas to form a whole, then covered with adhesive on the upper and lower sides, and vulcanised and pressed by a special template.

Product characteristics: the tape is pulled by the steel cable itself does not bear the traction force, only bear the material pressure. Withstand large capacity, can be used for both people and goods, single long-distance conveying.

Use scene: conveying coal, miners.

Categories

According to different materials can be divided into the whole structure of plastic (PVC) and PVC laminatebased on the rubber type (PVG).

PVC

typeModeling the entire core-wide conveyor belt for under inclination of 16 o dry conditions;

PVG

typeThe fabric core with rubber veneer conveyor belt, for under inclination of20 ° with wet conditions.

Features

The overall delaminating, high strength, impact resistant, tear resistance, mediated electrostatic, mechanicaioint performance.

Use

Apply to coal mine and other requirements of fire-resistant anti-static material conveying occasions.

Technical index

Item	Tensile N/mm		tearing force	Elongation %≥		Width mm	Length/roll m
	Warp	Weft	(N)≥	wrap	weft
680S	680	265	1090	15	18	650-1400	200
800S	800	280	1180
1000S	1000	300	1180
1250S	1250	350	1540
1400S	1400	350	1540
1600S	1600	400	-
1800S	1800	400	-
2000S	2000	400	-
2240S	2240	450	-
2500S	2500	450	-
The elongation should less than 4%

Cover rubber physics properties Standard: MT914-2002

Item	Value
Tensile MPa	≥10.0
Elongation %A	≥350
brasion mm3	≤200
